Universal testing machine with heating furnace (Type B)

Release time: 2024-07-10 03:41:12 Number of views: 126

Equipment Introduction:

Atmosphere annealing furnace is a device used for thermal treatment of materials in a specific atmosphere environment, widely used in fields such as metals, ceramics, semiconductor materials, etc. To achieve efficient and uniform heating effect, the atmosphere annealing furnace often uses short wave red wire heating twin tubes as the main heating element. This heating method has the advantages of energy saving, rapid heating, and uniform temperature.

Edit Content

Suitable for: colleges and universities, scientific research institutions, battery material production and battery production enterprises on button battery, analogue battery, half battery, three electrode battery, supercapacitor and other related electrochemical aspects of the research and testing.

Test items: detailed data of charge and discharge, cycle life, charge and discharge curves, charge and discharge efficiency, specific capacity, specific energy, DC resistance, leakage (self-discharge) current and other items.

Edit Content

Configuration

	1. The double-layer air-cooled structure greatly reduces the surface temperature of the shell; 2. High purity heating element with excellent acid and corrosion resistance; 3. The use of vacuum forming process made of refractory insulation materials, small heat loss, effectively reduce the use of equipment power; 4. Modular mechanism, durable and easy to maintain; 5. Touch screen operation, intuitive display of temperature curve.
Electrical Spec.	Three-phase 380V; 50HZ
Tmax	1150℃
rated power	4.5KW
thermocouple	Type B thermocouple
Furnace size	L1600×D770×H1520mm
Recommended heating rate	10℃/min
Temp. Accuracy	±℃
Control system		1, sintering process curve setting: dynamic display setting curve, equipment sintering can prestore multiple process curves, each process curve can be set freely; 2, can be reserved sintering, to achieve unattended sintering process curve sintering; 3, real-time display of sintering power and voltage information and record sintering data, and can be exported to achieve paperless recording; 4, with remote control, real-time observation of equipment status; 5, temperature correction: the difference between the main control temperature and the sample temperature, the whole sintering process for nonlinear correction.
heating element	Excellent acid and rot resistance
Cautions	1. When the furnace temperature of the equipment is ≥300℃, do not open the furnace to avoid damage; 2. Slight cracks caused by continuous use of the furnace are normal and do not affect the normal use of the equipment;
Service	One year limited warranty with lifetime support (warranty does not include consumable parts)

Disclaimer:
The product introduction content of this site (including product pictures, product descriptions, technical parameters, etc.) is for reference only. There may be some difference between the stated content and the actual situation due to the delay in updating. Please contact our customer service staff for confirmation. The information provided by this Site does not constitute any offer or acceptance. NOBODY will improve and modify any information on this site from time to time without prior notice.
